| Model | ASWT.9.0-20KW |
| Rated Power | 20KW |
| Maximum Output Power (W) | 28000 |
| Battery Bank Voltage (Vdc) | 240 |
| System output voltage (Vdc) | 220/380 |
| Start-up wind speed (m/s) | 3 |
| Rated wind speed (m/s) | 11.5 |
| Working wind speed (m/s) | 3-25 |
| Survival wind speed (m/s) | 50 |
| Generator efficiency | >0.85 |
| Wind energy utilizing ratio (cp) | 0.4 |
| Generator type | Permanent Magnet Alternator |
| Generator weight (kg) | 496 |
| Blade material / quality | GRP/3 |
| Blade diameter (m) | 9.0 |
| Speed regulation method | Yawning + Electromagnetism braking (Optional hydraulic braking) |
| Shutting down method | Manual + Automatic |
